Wall-mounted Hand Wash Basin – HB-788 Frencia
Compact Ceramic Wall Hung Basin for Bathrooms, Toilets & Cloakrooms
Overview
The Frencia HB-788 is a modern wall-mounted hand wash basin made from premium grade vitreous china. Its compact, space-saving design fits small bathrooms, guest toilets, and cloakrooms. Features a pre-punched tap hole, overflow, and smooth glazed surface for easy cleaning. Pairs perfectly with Frencia WC-788 toilet for a matching bathroom set.
Key Features
- Wall-Mounted Design: Floats off the floor for modern look. Saves space and makes floor cleaning easy.
- Grade A Vitreous China: High-gloss ceramic with anti-bacterial glaze. Stain, scratch, and chemical resistant.
- 450mm Width: Compact size fits tight spaces. Deep bowl prevents splashing.
- Single Tap Hole: Pre-punched 35mm center hole for standard basin mixer or pillar tap.
- Built-in Overflow: Prevents overfilling. Keeps bathroom safe from water damage.
- Easy Install: Mounts directly to wall with fixing bolts. No pedestal needed.
- Gloss White Finish: Matches all toilet and bathroom fittings. Timeless style.
- Rounded Edges: Smooth, safe edges. Family and child-friendly.
Technical Specifications
| Specification | Details |
|---|---|
| Model | HB-788 |
| Brand | Frencia |
| Type | Wall-Mounted / Wall Hung Basin |
| Material | Grade A Vitreous China Ceramic |
| Color | Gloss White |
| Dimensions | 450mm W x 350mm D x 150mm H |
| Bowl Depth | 120mm |
| Tap Hole | 1x 35mm, center position |
| Overflow | Yes, front position |
| Waste Outlet | 32mm / 1-1/4″ standard |
| Mounting | Wall bolts, 280mm centers |
| Weight | 9.5 kg |
| Water Capacity | 4.5 Liters |
What’s Included
- 1x HB-788 Ceramic Wall Hung Basin
- 1x Set of wall mounting bolts & plugs
- 1x Installation template
Not Included – Sold Separately
- Basin mixer tap or pillar tap
- 32mm bottle trap / P-trap
- Flexible hoses
- Angle valves
- Silicone sealant
Best for
Small bathrooms, guest toilets, cloakrooms, powder rooms, offices, and commercial washrooms. The compact 450mm width makes it ideal where space is limited. Mounts at standard 800–850mm height from floor to rim.
Recommended Pairings
| Item | Match With |
|---|---|
| Toilet | Frencia WC-788 One Piece Water Closet |
| Tap | Chrome basin mixer or tall pillar tap |
| Trap | Chrome bottle trap 32mm |
| Mirror | 450mm round or rectangular mirror |
Installation Tips
- Check Wall: Mount only on solid wall or use wall reinforcement. Not for plasterboard alone.
- Height: Standard rim height is 800–850mm from finished floor.
- Plumbing: 32mm waste pipe and 1/2″ hot/cold water points required behind basin.
- Seal: Apply silicone bead between basin and wall to prevent water ingress.
- Professional Install: Recommend licensed plumber for waste and water connections.
Care & Maintenance
- Clean daily with soft cloth and mild soap. Rinse well.
- Avoid bleach, acid cleaners, or scouring pads – damages glaze.
- For limescale, use white vinegar. Leave 10 min, then rinse.
- Check overflow monthly for blockages.
Product Tags: wall hung basin, wall mounted basin, HB-788, Frencia basin, ceramic basin, hand wash basin, bathroom basin, cloakroom basin, small basin, 450mm basin, white basin, basin with tap hole, overflow basin, basin ghana
SKU: HB-788
Warranty: 5 years warranty on ceramic
Note: Tap, waste, and trap not included. Color may vary slightly due to lighting and screen settings.
