Gasoline Engine – GX170F 7.5HP
212cc 4-Stroke OHV Petrol Engine – Replacement for Honda GX200 / GX210
Overview
The GX170F 7.5HP Gasoline Engine is a commercial-duty 212cc 4-stroke OHV air-cooled petrol engine. Delivers 7.5 horsepower at 3600 RPM with 13Nm torque. Features recoil start, low oil shutdown, transistor ignition, and standard 20mm keyway shaft. Direct replacement for Honda GX200 / GX210 engines. Ideal for water pumps, 3.5kW generators, plate compactors, concrete mixers, and farm equipment in Ghana.
Key Features
- 7.5P Powerful Output: 212cc OHV engine, 7.5HP / 5.2kW @ 3600 RPM. High torque for heavy loads.
- 20mm Straight Shaft: 20mm diameter x 50mm length with 5mm keyway. Universal fit for pumps, alternators, and pulleys.
- OHV Fuel Efficient Design: Overhead valve reduces fuel consumption by 20% vs side-valve engines. Low vibration.
- Easy Recoil Start: Ergonomic recoil with automatic decompression for quick start in one pull.
- Low Oil Protection: Engine automatically shuts off when oil is low to prevent seizure.
- Heavy-Duty Air Filter: Dual element paper + foam filter protects engine in dusty environments.
- 3.6L Fuel Tank: Runs 2 – 2.5 hours continuously. Uses regular unleaded petrol.
- Universal Mounting: Same bolt pattern as Honda GX200. Direct swap, no modification needed.
Technical Specifications
| Specification | Details |
|---|---|
| Model | GX170F |
| Type | 4-Stroke, Single Cylinder, OHV, Air-Cooled |
| Displacement | 212cc |
| Max Power | 7.0 HP / 5.2 kW @ 3600 RPM |
| Max Torque | 13.5 Nm @ 2500 RPM |
| Bore x Stroke | 70mm x 55mm |
| Compression Ratio | 8.5:1 |
| Starting System | Recoil Start |
| Ignition | Transistor Magneto, Non-Contact |
| Shaft Type | 20mm Straight Shaft, Keyway, 50mm Long |
| Rotation | Counter-Clockwise from PTO side |
| Fuel | Unleaded Petrol |
| Fuel Tank | 3.6 Liters |
| Oil Capacity | 0.6 Liters |
| Oil Type | SAE 30 / 10W-30 |
| Air Filter | Dual Element (Paper + Foam) |
| Weight | 16.5 kg |
| Dimensions | 380mm L x 320mm W x 350mm H |
What’s Included
- 1x GX170F 7.5HP Gasoline Engine
- 1x Air Filter Assembly
- 1x Fuel Tank with Cap & Fuel Filter
- 1x Spark Plug (pre-installed)
- 1x Engine Tool Kit
- 1x User Manual
Compatible Equipment
| Machine | Application |
|---|---|
| Water Pump | 2″ & 3″ high-pressure pumps |
| Generator | 3.0kW – 3.5kW generators |
| Plate Compactor | 90kg – 120kg compactors |
| Concrete Mixer | 350L – 400L drum mixers |
| Concrete Vibrator | Flexible shaft vibrators |
| Go-Kart / Farm | Go-karts, threshers, tillers, sprayers |
First Time Use
- Add Oil: Engine ships dry. Add 0.6L SAE30 oil before starting.
- Add Fuel: Fill with clean unleaded petrol only.
- Check Shaft: Align pulley/belt. Do not hammer shaft.
- Break-In: Run at half load for first 5 hours, then change oil.
Product Tags: GX170F, 7HP engine, gasoline engine, 212cc engine, petrol engine, GX200 replacement, OHV engine, water pump engine, generator engine, 20mm shaft engine, 4 stroke engine ghana
SKU: ENG-GX170F-7.5HP
Note: Comes without fuel and oil. Replacement for Honda GX200 / GX210. Professional installation recommended.
